Description
MGS506 — product overview
A fluxgate sensor used in the Yokogawa TMC magnetic-heading system. It senses the magnetic-compass arrangement for the associated display/interconnect equipment.
SEANAV MARINE selling price: AED 5,428, excluding tax. Availability and delivery time are confirmed with your quotation.
Key features and application
- Sensor installation and alignment affect the heading supplied to connected equipment
- Sensor replacement requires matching of the bracket, cable and order suffix
Technical specifications
| Sensor type | Fluxgate |
|---|---|
| System role | Magnetic-heading sensing |
| Reference manual | IM80B91C01-E |
| Associated legacy units | MPC430 TMC display and MPN031 interconnect |
| Variant distinction | MGS508 is separately identified as the THD sensor |
Model and variant note: No heading accuracy, cable length or environmental rating is claimed without an exact sensor datasheet.
Supply scope and installation
Sensor; confirm bracket and cable assembly separately.
Provide the complete model suffix, equipment nameplate and relevant mounting or wiring drawing so SEANAV MARINE can match the supplied item to the vessel. Manufacturer drawings and nameplate ratings govern installation. Measurements tied to a specific variant are identified above.
Product questions
What is MGS506 used for?
A fluxgate sensor used in the Yokogawa TMC magnetic-heading system. It senses the magnetic-compass arrangement for the associated display/interconnect equipment.
What is included in this price?
Sensor; confirm bracket and cable assembly separately. The listed AED 5,428 is taken from SEANAV’s April 2026 accessory price list. Confirm current validity, freight and any additional installation items.
How do I order the correct version?
Send the complete MGS506 order reference, quantity, vessel name, existing equipment photographs and delivery port to SEANAV MARINE. Include the fitted equipment’s electrical ratings and required completion date where applicable.
Manufacturer documents
Specifications above identify their relevant model or drawing variant. Legacy manufacturer references are provided for technical identification; confirm the current delivered configuration before purchase.
