Description
The Magnetron E3560 is precisely engineered for high-performance X-band radar systems, offering robust features for demanding radar applications. Operating within a fixed frequency range of 9380 to 9440 MHz, it ensures a steady and reliable signal output, crucial for accurate radar operation. With a peak output power of 6kW, the E3560 magnetron delivers powerful radar performance, enhancing target detection and overall reliability in diverse environments.
This magnetron is designed with optimized electrical characteristics for efficient and long-lasting performance. It requires a heater voltage between 6.0 to 6.6V and draws a heater current of 0.55A, with a 60-second preheat time to reach peak functionality. The peak anode voltage ranges from 4.4 to 4.8kV, adding an extra level of stability. These specifications make it ideal for environments where consistency and power output are essential.
The E3560 magnetron absolute maximum ratings, including a peak anode current range of 2.5 to 6.0A, a duty cycle of 0.001, and pulse durations from 0.05 to 1.25 μs, set strict limits to prevent overload and ensure durability. Its built to handle up to 100°C at the anode temperature, with a VSWR of 1.5:1 at the output coupler, making it a resilient choice for radar applications that demand exact specifications and peak power performance.
Technical Specifications:
Frequency Range: 9380 – 9440 MHz
Peak Output Power: 6 kW
Heater Voltage: 6.0 – 6.6V
Heater Current: 0.5 – 0.6A
Preheat Time: 60 seconds
Peak Anode Voltage: 4.4 – 4.8 kV
Peak Anode Current: 2.5 – 6.0A
Duty Cycle: 0.001
Pulse Duration: 0.05 – 1.25 μs
Max Anode Temperature: 100°C
VSWR at Output Coupler: 1.5:1
